OpenVox SWG-2032G gateway | gsm gateway provider

 OpenVox SWG-2032G gateway supports 32 GSM Channels and 1 Ethernet interface, And the band is 850/900/1800/1900 MHz.

SWG-2032G gateway supports multiple codecs, including G.711U, G.711A, GSM, G.722, G.723, G.726, G.729 multiple coding. The GSM gateway will be 100% compatible with Asterisk, Elastix, trixbox, 3CX, Free SWITCH SIP server and VOS VoIP operating platform. It can help users reduce telecommunications and communication costs.

Technical Specifications

·         32 GSM Channels

·         1 SIM card per GSM channel

·         1 10/100M LAN interfaces

·         16 Standard SMA-K interfaces

·         LCD dimension2.4"

·         LCD resolution ratio 240*400

·         Storage temperature range -20~70

·         Operation temperature range 0~40

·         Operation humidity range 10%~90% non-condensing

·         Power source 12V DC/2.33A

·         Power 36W

·         Dimension 36cm*21cm*4.44cm

·         Weight 1.544Kg

Features

System Features

·         Abundant CodecsG.711UG.711AGSMG.722G.723G.726G.729

·         Simple and convenient configuration via Web GUI

·         Firmware Update by HTTP

·         Automatically Reboot

·         Support DISA

·         Mutiple Detailed LOG Output

·         Call Status Display

·         Mobile number portabilityMNP

·         CDR

·         Support Configuration files backup and upload

·         Support for Custom scripts, diaplans

·         Restore Factory Settings

GSM Features

·         CallerID Display & Hide

·         GSM 850/900/1800/1900 MHz

·         Real Open API Protocol

·         Call Duration Limitation

·         SMSC/SMS/USSD

·         PIN Identification

·         Voice Codec

·         Ports Group Management

·         SMS Remotely Controlling Gateway

·         SMS Bulk Transceiver, Sent to Email and Auto- Matically Resend

·         SMS Forwarding and Quick Reply

VoIP Characters

·         Support SIP, IAX2 Protocol

·         Add, Modify & Delete SIP/IAX2 Trunk

·         SIP/IAX2 Registration with Domain

·         DTMF ModeRFC2833/Inband/SIPInfo

·         Multiple SIP/IAX2 Registrations modes

Network

·         IPv4UDP/TCPDHCPTELNETHTTP/HTTPSTFTP

·         HTTP/SSHOptical Telnet)

·         Ping & Traceroute Command on the Web

·         Simple Security Strategy white list, black list, security rules
